Material: PA + Fiberglass or Recycled ABS (Eco-Line)
Colors: Black or Grey
Panel Thickness: 1.5 mm (0.06 in)*, 3.0 mm (0.12 in), or 5.0 mm (0.20 in)
(*1.5 mm only available in Black)
Air Flow Opening: 2,280.0 mm2 (89.76 in2)
Certifications: 95/98/EC for Flammability
3D PDF requires Adobe® Reader® v7.0 or higher
Click here to download latest version.
Authorization Required
To obtain a username and password
Please contact a Euramtec Corp. Sales Representative.
TEL: (248) 473-8660
Technical PDF requires Adobe® Reader® v7.0 or higher
Click here to download latest version.
Family Number: P.236
Part Number(s):
S-63009 - PA + Glass Fiber - 1.5 mm (0.06 in) Panel Thickeness - Black Color
S-65718 - PA + Glass Fiber - 3.0 mm (0.12 in) Panel Thickness - Black Color
S-60051 - PA + Glass Fiber - 3.0 mm (0.12 in) Panel Thickness - Grey Color (RAL 7043)
S-67597 - PA + Glass Fiber - 5.0 mm (0.20 in) Panel Thickness - Black Color
S-61712 - PA + Glass Fiber - 5.0 mm (0.20 in) Panel Thickness - Grey Color (RAL 7006)
S-62921 - PA + Glass Fiber - 5.0 mm (0.20 in) Panel Thickness - Grey Color (RAL 7043)
Eco-Line:
S-63269 - Recycled ABS - 5.0 mm (0.20 in) Panel Thickness - Black Color
