S-ACT-045N Door Lock Actuator

Euramtec’s S-ACT-045N Door Lock Actuator provides high force in a small package. At 45 Newtons (10.1lbs), this actuator has the greatest linear force of any of the actuators. In addition, the ACT-045N incorporates many unique safety features: directed clutch for motor protection, overload protection lock motor, and a water resistant sealing boot. The actuator also features integrated 7 inch wire leads, a rotatable and changeable connector head, and comes complete with all necessary mounting hardware.

  • Specifications
  • Photos
  • 3D PDF
  • Technical PDF

Gear Motor Driven Directed Clutch Actuator
Force: 45 Newtons/10.11 lbs.
Voltage: 9 to 16 VDC
Nominal Current Draw: 2A
Endurance: 20,000 Cycles
Operational Temp. Range: -30°C to +85°C

  • Overload Protected Lock Motor
  • Water-resistant Boot Sealed
  • Rotatable & Changeable Head
  • Integrated 7in Leads
  • Mounting Hardware Included
    •
    Available in 2-wire slave or 5-wire master configurations.
